    Pipe Coating

    Download Datasheet

    DESCRIPTION

    PU5617 is 1:1, fast setting; spray applied two component polyurethane coating

    USES

    Protection for steel, iron, pipework and tanks

    BENEFITS

    • Fast Curing
    • Solvent Free
    • No primer needed
    • 100% Solids

    PRODUCT SPECIFICATION

    Product: Leeson Pipe Coatings

    Thickness: Typically 2mm

    Manufacturer: Leeson Polyurethanes Ltd.

    Telephone: + 44 (0) 1926 833367

    SUBSTRATE REQUIREMENTS

    The substrate should be dry to 75%RH as per BS8204 and free from rising damp.

    Concrete: Primer must be used. Minimum 25N/mm2, free from laitance, dust and other contamination.

    PRODUCTS INCLUDED IN THIS SYSTEM

    Top Coat:               Leeson PU5617                    2.2kg/m2

    Detailed installation instructions are available
    on request.

    INSTALLATION SERVICE

    The installation should be carried out by an experienced contractor, details of contractors in your area can be obtained by contacting the company.

    IMPORTANT NOTE

    Leeson Polyurethanes’ products are guaranteed against defective materials and manufacture and are sold subject to its standard Terms and Conditions of Sale, copies of which can be obtained on request.

    UV DISCOLOURATION

    *Please note that PU5617 are based on MDI polyurethane technology which is subject to colour change under exposure to UV. The strength of the system is not affected.

    Please contact the company for further details.


    Download Datasheet
    Contact us for more information

    TECHNICAL INFORMATION

    The figures below are typical properties achieved in laboratory tests at 21oC and 55% Relative Humidity.

    Temperature Resistance

    Resistant to temperatures of over 70oC for long periods.

    Chemical Resistance

    To various acids, diesel and petrol as well as strong bases.

    Elongation @ Break (PU5617)

    <10% to BS2782 Part 3

    Tensile Strength (PURA 5617)

    Min 8 N/mm2 to BS2782 Part 3

    Speed of Cure

    19oC Instant

    AFTERCARE – CLEANING & MAINTENANCE

    The surface should be cleaned regularly

    ENVIRONMENTAL IMPACT

    The finished system is assessed as non-hazardous to health and the environment. The long service life and seamless surface reduce the need for repairs, maintenance and cleaning. Environmental and health considerations are controlled during manufacture of the products by Leeson Polyurethanes staff.
